Dujiangyan Hengtong Magnetoelectric Co., Ltd.
| Place of Origin: | Sichuan, China |
|---|---|
| Brand Name: | HTCD |
| Certification: | IATF16949,MSDS,RoHS,SGS,ISO9001 |
| Model Number: | W039H |
| Minimum Order Quantity: | 100K |
| Price: | Negotiation |
| Packaging Details: | Customized packaging |
| Delivery Time: | 10-15 |
| Payment Terms: | T/T |
| Supply Ability: | 300k pcs |
| Name: | Ferrite Ring Magnet | Type: | Hard |
|---|---|---|---|
| Size: | Customized Magnet Size | Composite: | Ferrite Ring Magnet, Ceramic Magnet / Ferrite Magnet |
| Working Temperature: | 250ºC | Application: | Automobile Motors, Motorcycle Motors, General Machinery Motors, Household Appliance Motors, Household Fan Motors, Frequency Conversion Motors, Water Pump Motors, Etc. |
| Processing: | Sintered Magnet | Material: | SrO(Strontium Oxide) OR BaO( Barium Oxide ) And Fe2o3( Ferric Oxide) |
| Shape: | Round, Block/Rectangular,Disc,Bar,Ring,Segment,Ect | Coating: | No Coating |
| Certification: | IATF16949,MSDS,RoHS,SGS,ISO9001 | ||
| High Light: | DC Motors Hard Ferrite Magnets,Speakers Hard Ferrite Magnets,IATF16949 ferrite magnet rings |
||
1. Isotropic ferrite magnets are not oriented and can be magnetized in any direction;
2. Anisotropic ferrite magnets are different, they are all oriented in the manufacturing direction, and should be magnetized in the direction of orientation.
Specification
1. Material: ferrite powder
2. Shape: Arc, Block, Bar, Ring, Cube, Disc, or others.
3. Application: Widely used in ammeter, speaker, audio, phone, TV, dynamo, DC permanent magnet motors (used in cars), etc
| Gade | Br(mT) | Hcb(KA/m) | Hcj(KA/m) | (BH)max(KJ/m3) | ||||
| mT | Gs | KA/m | Oe | KA/m | Oe | KJ/m3 | MGOe | |
| HT-2 | 380-395 | 3800-3950 | 250-270 | 3140-3391 | 260-285 | 3265-3580 | 29.0-31.5 | 3.64-3.95 |
| HT-2A | 390-400 | 3900-4000 | 270-285 | 3391-3580 | 275-300 | 3454-3768 | 29.0-31.0 | 3.64-3.89 |
| HT-3 | 405-415 | 4050-4150 | 250-270 | 3140-3391 | 260-275 | 3265-3768 | 31.0-33.5 | 3.89-4.20 |
| HT-3A | 415-425 | 4150-4250 | 230-250 | 2889-3140 | 240-260 | 3014-3265 | 31.0-34.0 | 3.89-4.27 |
| HT-3B | 400-415 | 4000-4150 | 275-290 | 3454-3642 | 285-310 | 3580-3893 | 31.8-33.7 | 4.0-4.23 |
| HT-4 | 410-420 | 4100-4200 | 300-315 | 3768-3956 | 310-330 | 3893-4145 | 31.0-35.0 | 3.89-4.40 |
| HT-4A | 420-435 | 4200-4350 | 260-285 | 3265-3579 | 270-290 | 3391-3642 | 33.0-37.0 | 4.14-4.64 |
| HT-4B | 395-410 | 3950-4100 | 310-330 | 3893-4145 | 360-380 | 4521-4772 | 28.0-32.0 | 3.52-4.02 |
| HT-5 | 410-430 | 4100-4300 | 300-320 | 3768-4019 | 375-390 | 4710-4898 | 33.0-36.0 | 4.14-4.52 |
1. What are neodymium magnets? Are they the same as "rare earth"?
Neodymium magnets are a member of the rare earth magnet family. They are called "rare earth" because neodymium is a member of the "rare earth" elements on the periodic table. Neodymium magnets are the strongest of the rare earth magnets and are the strongest permanent magnets in the world.
2. What are neodymium magnets made from and how are they made?
Neodymium magnets are actually composed of neodymium, iron and boron (they are also referred to as NIB or NdFeB magnets). The powdered mixture is pressed under great pressure into molds. The material is then sintered (heated under a vacuum), cooled, and then ground or sliced into the desired shape. Coatings are then applied if required. Finally, the blank magnets are magnetized by exposing them to a very powerful magnetic field in excess of 30 KOe.
3. How is the strength of a magnet measured?
Gaussmeters are used to measure the magnetic field density at the surface of the magnet. This is referred to as the surface field and is measured in Gauss (or Tesla). Pull Force Testers are used to test the holding force of a magnet that is in contact with a flat steel plate. Pull forces are measured in pounds (or kilograms).
4. What does the "N rating", or grade, of the neodymium magnets mean?
The grade, or "N rating" of the magnet refers to the Maximum Energy Product of the material that the magnet is made from. It refers to the maximum strength that the material can be magnetized to. The grade of neodymium magnets is generally measured in units millions of Gauss Oersted (MGOe). A magnet of grade N42 has a Maximum Energy Product of 42 MGOe. Generally speaking, the higher the grade, the stronger the magnet
