Permanent Magnet Ferrite Tiles For Home Dishwashers Household Appliances Ferrite Magnets

Product Details

Place of Origin: Sichuan, China

Brand Name: XINHENG

Certification: IATF16949,ISO9001

Model Number: W023

Payment & Shipping Terms

Minimum Order Quantity: 1000pcs

Price: Negotiation

Packaging Details: Carton+pallet

Delivery Time: 10-15days

Payment Terms: T/T, L/C, D/P, T/T, Western Union, MoneyGram

Supply Ability: 10000 ton per year

Get Best Price
Highlight:

Household Appliances Ferrite Magnets

,

Home dishwashers Ferrite Magnets

,

Permanent magnet ferrite tiles

Product Name:
Ferrite Motor Magnets
Application:
Air Conditioner Motor
Shape:
Arc,Tile
Type:
Anisotropic Sintered Magnet
Composite:
Ferrite Strontium Powder
Size:
(R30.3mm-20.3rmm)×16.32mm
Processing:
Wet Pressed
Coating:
No Coating
Container Capacity:
920pcs
Product Name:
Ferrite Motor Magnets
Application:
Air Conditioner Motor
Shape:
Arc,Tile
Type:
Anisotropic Sintered Magnet
Composite:
Ferrite Strontium Powder
Size:
(R30.3mm-20.3rmm)×16.32mm
Processing:
Wet Pressed
Coating:
No Coating
Container Capacity:
920pcs
Permanent Magnet Ferrite Tiles For Home Dishwashers Household Appliances Ferrite Magnets

Permanent magnet ferrite tiles for home dishwashers Household Appliances Ferrite Magnets

 The intorduce of air conditioner:

Air conditioning motor is an important part of the air conditioning system, it is responsible for driving the air conditioning compressor and fan operation, so as to achieve the cooling or heating function of the air conditioning system. Air conditioning motor usually uses AC motor or DC motor, according to the design and requirements of the air conditioning system, the power size and movement of the motor will be different.

Air conditioning motor usually has the characteristics of high efficiency, low noise and stable operation, and its performance and quality directly affect the cooling or heating effect of the air conditioning system. Therefore, the selection of high-quality air conditioning motor is very important for the operation stability and energy saving performance of air conditioning system.

The air conditioning motor plays an important role in the air conditioning system and is one of the key components of the normal operation of the air conditioning system and the provision of a comfortable environment.


Our company manufactures an-isotropic ceramic strontium ferrite magnet made by means of wet compression molding.

Permanent Magnet Ferrite Tiles For Home Dishwashers Household Appliances Ferrite Magnets 0

What is permanent magnet ferrite?

Permanent magnet ferrite is a hexagon structure compound with uniaxial anisotropy, mainly barium, strontium, lead three kinds of ferrite and their composite solid solution, there are the same magnetic and opposite magnetic points, because this kind of ferrite material in the external magnetization field disappeared, still can retain a strong constant remanent magnetic property for a long time, can be used to generate a stable magnetic field on the external space.

How to determine the performance of the product?

There are four main indicators to measure the performance of permanent magnet materials: residual magnetism, coercive force, intrinsic coercive force, and maximum magnetic energy product,The finished permanent magnet ferrite has a high coercivity and is not easy to demagnetize after magnetization.


What are the advantages of the permanent magnet ferrite we produce?

1,Stable magnetic properties: permanent magnet ferrite has high coercivity and remanence, stable magnetic properties, and is not easily affected by external influences.
2,High temperature resistance: permanent magnet ferrite has good high temperature resistance and is suitable for use in high temperature environment.
3,High temperature coefficient of resistance to saturated magnetic field: The magnetic properties of permanent magnet ferrite decay slowly at high temperatures, with a high temperature coefficient of resistance to saturated magnetic field.
4,Low cost: The raw material price of permanent magnet ferrite is low, the production process is simple, and the cost is relatively low.
5,Long service life: permanent magnet ferrite has a long service life, is not easy to demagnetize, low maintenance costs.
6,Good rare earth substitution: permanent magnet ferrite can replace some rare earth magnets, reduce the dependence on rare earth and reduce the consumption of rare earth resources.


PHYSICAL PROPERTIES OF SINTERED FERRITE MAGNETS

  Units Sintered Ferrite (Ceramic)
Curie Temperature ºC 450
Maximum Operating Temperature ºC 350
Hardness Hv >530
Density g/cm3 4.8 – 5.0
Relative recoil permeability μrec 1.05-1.1
Temperature Coefficient Br %/ºC -0.18
Temperature Coefficient iHc %/ºC 0.11-0.40
Anti-Bending Strength N/m2 (0.5-0.9)×108
Anti-Compressive Strength N/m2 ≥6.9×108
Anti-Tensile Strength N/m2 (0.2-0.5)×108
Specific Heat J/kg·K 600-900
Resistivity Q.cm >104



What's the application of Xinheng's permanent ferrite magnets?

Xinheng mainly manufactures the following types of ceramic arc segment magnets:

  • Automotive motor magnet including automobile starter motor magnet, automobile wiper motor magnet, automobile rolling window motor magnet, automobile heating and cooling fan motor magnet, automobile seat motor magnet, automobile sunroof motor magnet, automobile powsteering motor magnet, automobile tailgate motor magnet, automobile oil pump motor magnet, automobile ABS anti-lock motor magnet, etc.
  • Inverter home appliance magnet including inverter washing machine motor magnet, inverter refrigerator motor magnet, inverter air-conditioner motor magnet,etc.
  • Fan motor magnet including ceiling fan motor magnet, floor fan magnet, etc.
  • Motorcycle motor magnet including motorcycle starter motor magnet, motorcycle flywheel magneto magnet, etc.
  • Electrical tool motor magnet including cutting machine motor magnet, electric sawing machine motor magnet, lawn mower motor magnet, gasoline generator magnet, etc.
  • Actuator motor magnet including medical bed actuator motor magnet, TV lifting bracket actuator motor magnet, desk lifting actuator motor magnet, smart home appliance actuator motor magnet, etc.

Permanent Magnet Ferrite Tiles For Home Dishwashers Household Appliances Ferrite Magnets 1


FERRITE POWDER GRADE OF MOTORCYCLE MOTORS MAGNET



Grade

Br(mT) Hcb(KA/m) Hcj(KA/m) (BH)max(KJ/m3)
mT Gs KA/m Oe KA/m Oe KJ/m3 MGOe
Y33 410-430 4100-4300 220-250 2760-3140 225-255 2830-3200 31.5-35.0 3.9-4.4
Y33H 410-430 4100-4300 250-270 3140-3390 250-275 3140-3450 31.5-35.0 3.9-4.4
Y33H-2 410-430 4100-4300 285-315 3580-3960 305-335 3830-4200 31.8-35.0 4.0-4.4
Y34 420-440 4200-4400 200-230 2510-2890 205-235 2570-2950 32.5-36.0 4.1-4.4
Y35 430-450 4300-4500 215-239 2700-3000 217-241 2730-3030 33.1-38.2 4.1-4.8
Y36 430-450 4300-4500 247-271 3100-3400 250-274 3140-3440 35.1-38.3 4.1-4.8
Y38 440-460 4400-4600 285-305 3580-3830 294-310 3690-3890 36.6-40.6 4.6-4.8
Y40 440-460 4400-4600 330-354 4150-4450 340-360 4270-4520 37.6-41.8 4.7-5.2



Permanent Magnet Ferrite Tiles For Home Dishwashers Household Appliances Ferrite Magnets 2
Permanent Magnet Ferrite Tiles For Home Dishwashers Household Appliances Ferrite Magnets 3
